£137.16
excl. VAT
£164.59 incl. VAT
£164.59
incl. VAT
£137.16 excl. VAT
Free shipping
In stock
Expected to ship on Thursday 17 September
Product details
| Application range | Construction machines, Forestry machinery, Agricultural machinery, Mechanical engineering |
|---|---|
| Belt width | 22 mm |
| Benefits | Can be used with different shaft diameters, Fast and simple to assemble and dismantle |
| Consists of | V-belt pulley, No taperlock adjustment bush supplied |
| Designed for belt type | V-Belt |
| Designed for V-belt profile | C, SPC |
| Details | With taperlock bore |
| FWorking width | 85 mm |
| Hub width | 45 mm |
| JChamber diameter | 144 mm |
| KHub offset 1 | 20 mm |
| Lock type | 2517 |
| Material | Cast iron |
| Max. bore diameter | 60 mm |
| Max. speed | 30 m/s |
| MHub offset 2 | 20 mm |
| Number of grooves | 3 |
| OPulley outside diameter | 209.6 mm |
| PPitch diameter | 200 mm |
| Pulley type | 3 |
| Technical info | Recommended minimum diameter of the v-belt pulley:, For VB22 - 180 mm, For SPC - 224 mm, For XPC - 180 mm |
| Unit | Each |
Logistics
| EAN | 4014486248432 |
|---|---|
| Unit of measure | EA |
| Weight | 10300 g |
| Dimensions | 210 × 210 × 85 mm |
| Dangerous goods | No |
