Product details
| Application range | In conjunction with an additional switch, it can also be used as a main switch |
|---|---|
| Height | 43 mm |
| Length | 100 mm |
| Properties | Monitors the output voltage and corrects overvoltage and undervoltage, Undervoltage setting for 12 V is 9–12 V, Overvoltage setting for 12 V is 15.5 V, Undervoltage setting for 24 V is 18–24 V, Overvoltage setting for 24 V is 31 V |
| Unit | Each |
| Voltage range | 12-24 V |
| Weight | 206 g |
| Width | 89 mm |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 252 g |
| Dimensions | 160 × 161 × 48 mm |
| Dangerous goods | No |
