£674.93
excl. VAT
£809.92 incl. VAT
£809.92
incl. VAT
£674.93 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Application range | Ground chain, agricultural machines, Belt conveyor, Salt spreaders, Road sweepers, Cement mixers |
|---|---|
| Benefits | Higher torque with simple hydraulic motor |
| Connection 1 inside diameter | 25.00 mm |
| Connection 1 outside diameter | n/a |
| Connection 1 Outside Diameter inch and splines | n/a |
| Connection 2 inside diameter | 45.00 mm |
| Connection 2 outside diameter | n/a |
| Connection 2 Outside Diameter inch and splines | n/a |
| Connection 3 outside diameter | n/a |
| Connection 3 Outside Diameter inch and splines | n/a |
| Contains oil | No |
| Details | Robust design made of cast iron |
| Max. oil capacity | 2.5 l |
| Max. oil change interval | 500 h |
| Max. output torque | 1900 N·m |
| Model | RT190 |
| Oil SAE viscosity grade | 80W-90 |
| Product details | For DANFOSS OMP/OMR, The gearbox is delivered without oil and must be filled before first use., First oil change after 50-70 operating hours, then after 500-700 operating hours or at least once a year. |
| Properties | Alternative to chain drive |
| Ratio factor | 10.2:1 |
| Unit | Each |
| Weight | 28 kg |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 26400 g |
| Dimensions | 320 × 250 × 145 mm |
| Dangerous goods | No |
