£277.76
excl. VAT
£333.31 incl. VAT
£333.31
incl. VAT
£277.76 excl. VAT
Free shipping
In stock
Expected to ship on Friday 18 September
Product details
| Application range | Fertiliser pump, Shredder, Light balers |
|---|---|
| Benefits | Prevents against subsequent damage, Easy to start up |
| Clutch type code | LB |
| Connection outside diameter machine side inch and splines | 1.3/8-6 |
| Details | Drive fully disconnected, Repairable by replacing a shear bolt |
| Locking type by machine side | Clamp cone |
| Max static torque | 3600 N·m |
| Properties | Regardless of direction of rotation, Power transmission via shear bolts |
| Shaft size code | S8, H8, G8 |
| Share bolts circle radius | 52 |
| Share bolts thread diameter | M12 |
| Share bolts thread length | 55 |
| Shear bolts quality | 8.8 (steel) |
| Shear bolts thread pitch | 1.75 mm |
| Technical info | Protects against blockages and overload |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 5403 g |
| Dimensions | 170 × 140 × 118 mm |
| Dangerous goods | No |
