Product details
| Application range | Excavator shovel, crane shovel and front loader shovel |
|---|---|
| B1Sloping horizontal width | 40 mm |
| BEdge strip total width | 150 mm |
| Benefits | Long service life |
| C1Min. working thickness | 6 mm |
| CThickness | 25.4 mm |
| Details | Extremely wear resistant rolled steel |
| Edge strip total length | 2500 mm |
| Hardness HB | 470 |
| Technical info | Electrical welding as well as MIG/MAG welding, The material to be welded must first be heated to a temperature between 50° and 75°C, and must be cooled in a controlled manner, Electrical: a basic welding rod is recommended, but a standard welding rod can also be used, MIG-MAG: SG3 wire is recommended, but standard SG2 wire can also be used |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 67000 g |
| Dimensions | 2500 × 160 × 25 mm |
| Dangerous goods | No |
