£53.84
excl. VAT
£64.61 incl. VAT
£64.61
incl. VAT
£53.84 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Basic radial load dynamic | 22500 N |
|---|---|
| Basic radial load static | 13100 N |
| Bearing model type | Angular contact ball bearings |
| BWidth | 22.2 mm |
| Contact angle | 30 ° |
| dInside diameter | 17 mm |
| DOutside diameter | 47 mm |
| Inside diameter of outer ring | 38.97 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 16600 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | 3303-BD-XL-TVH |
| Outside diameter of inner ring | 27.14 mm |
| Radial internal clearance code | CN |
| Ref rotation speed | 15000 r/min |
| Regreasable | Yes |
| Rows number | 2 |
| Sealing | Open |
| Surface treatment | n/a |
| Unit | Each |
| Weight | 0.174 kg |
Logistics
| EAN | 40128024828504064327818409 |
|---|---|
| Unit of measure | EA |
| Weight | 177 g |
| Dimensions | 50 × 50 × 28 mm |
| Dangerous goods | No |
You might also like
BPA000089642
FAG Angular contact ball bearing 17x47x22.2mm INA/FAG 33032RS
£54.56 excl.
£65.47 incl.
In stock
Expected to ship on Friday 18 September
BPA000089661
FAG Angular contact ball bearing 17x47x22.2mm INA/FAG 3303BDXL2HRSTVHC3
£59.90 excl.
£71.88 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000089662
FAG Angular contact ball bearing 17x47x22.2mm INA/FAG 3303BDXLTVHC3
£51.41 excl.
£61.69 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000380751
FAG Housing unit UCP UCP207
