£52.81
excl. VAT
£63.37 incl. VAT
£63.37
incl. VAT
£52.81 excl. VAT
In stock
Expected to ship on Tuesday 22 September
Product details
| Application range | High radial loads and high speeds, Gearbox, Gearbox, Worm gear shaft, Spring plates |
|---|---|
| Basic radial load dynamic | 61000 N |
| Basic radial load static | 48000 N |
| Bearing model type | Cylindrical roller bearings |
| BWidth | 19 mm |
| Consists of | Cylindrical bearing, Inner ring NU |
| dInside diameter | 30 mm |
| DOutside diameter | 72 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 14200 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | NU306-E-TVP2 |
| Properties | Outer ring with 2 fixed ribs, Inner ring without rib, Axial displacement of shaft with regard to housing in 2 directions |
| Radial internal clearance code | CN |
| Ref rotation speed | 10000 r/min |
| Rows number | 1 |
| Sealing | Open |
| Unit | Each |
| Weight | 3.664 kg |
Logistics
| EAN | 4012801179720 |
|---|---|
| Unit of measure | EA |
| Weight | 366 g |
| Dimensions | 75 × 75 × 22 mm |
| Dangerous goods | No |
You might also like
BPA000326418
FAG Cylindrical roller bearing 30x72x19mm INA/FAG NU306EXLTVP2C3
£48.99 excl.
£58.79 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000150846
FAG Deep groove ball bearing 90x140x24mm INA/FAG 6018C3
£65.06 excl.
£78.07 incl.
Backorder available
Usually ships within 3–8 weeks
Free shipping
BPA000067583
FAG Spherical roller bearing 50x110x27mm INA/FAG 21310E1XLKTVPB
£176.12 excl.
£211.34 incl.
Backorder available
Usually ships within 3–8 weeks
Free shipping
BPA000067600
FAG Spherical roller bearing 60x130x31mm INA/FAG 21312E1
£221.32 excl.
£265.58 incl.
In stock
Expected to ship on Thursday 24 September
BPA000088702
FAG Angular contact ball bearing 12x32x15.9mm INA/FAG 3201C3
£34.65 excl.
£41.58 incl.
In stock
Expected to ship on Thursday 24 September
BPA000155825
FAG Deep groove ball bearing 20x52x21mm INA/FAG 62304A2RSRC3
£18.67 excl.
£22.40 incl.
Backorder available
Usually ships within 3–8 weeks
Recently viewed
BPA000307307
Kramp Dungarees, size 3XL, green/blue, Kramp Original KW103030082122
£56.21 excl.
£67.45 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000311484
Unbranded Tapered roller bearing 31.75x59.13x17.78mm LM67000LANB
