£225.40
excl. VAT
£270.48 incl. VAT
£270.48
incl. VAT
£225.40 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Application range | High radial loads and high speeds, Gearbox, Gearbox, Worm gear shaft, Spring plates |
|---|---|
| Basic radial load dynamic | 166000 N |
| Basic radial load static | 168000 N |
| Bearing model type | Cylindrical roller bearings |
| BWidth | 26 mm |
| Consists of | Cylindrical bearing, Inner ring NUP |
| dInside diameter | 80 mm |
| DOutside diameter | 140 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 7000 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | NUP216-E-TVP2 |
| Properties | Outer ring with 2 fixed ribs, Inner ring with 1 fixed and 1 loose rib, Fixed bearing, to lock shaft axially in 2 directions |
| Radial internal clearance code | CN |
| Ref rotation speed | 4800 r/min |
| Rows number | 1 |
| Sealing | Open |
| Unit | Each |
| Weight | 0.159 kg |
Logistics
| EAN | 4012801236225 |
|---|---|
| Unit of measure | EA |
| Weight | 1617 g |
| Dimensions | 145 × 145 × 30 mm |
| Dangerous goods | No |
You might also like
BPA000153362
FAG Deep groove ball bearing 25x47x16mm INA/FAG 630052RS
£16.47 excl.
£19.76 incl.
Backorder available
Usually ships within 3–8 weeks
Free shipping
BPA000153603
FAG Deep groove ball bearing 19x72x19mm INA/FAG 6306H2RS
£140.48 excl.
£168.58 incl.
In stock
Expected to ship on Friday 18 September
Free shipping
BPA000150619
FAG Deep groove ball bearing 90x115x13mm INA/FAG 618182RS
£125.66 excl.
£150.79 incl.
In stock
Expected to ship on Friday 18 September
BPA000380949
FAG Housing unit UKP UKP207
