FAG Self-aligning ball bearing 30x72x19mm INA/FAG 1306TVHC3

About this product

A FAG self-aligning ball bearing (model 1306TVHC3) with a 30 mm bore diameter, 72 mm outside diameter, and 19 mm width, supplied as a single piece. The bearing features a cylindrical bore and inner ring, and is designed with two rows of balls to accommodate considerable shaft deflection or misalignment. It carries a dynamic radial load rating of 21700 N and a static radial load rating of 6300 N, with a radial internal clearance code of C3. The bearing is manufactured from steel and rated for operation between −30 °C and 120 °C, with a maximum rotation speed of 11100 r/min and a reference speed of 8700 r/min. The unsealed design is suitable for conveyor belts and steel production plant applications. The bearing weighs 387 g and carries the EAN 4012801159333.
