FAG Self-aligning ball bearing 55x120x29mm INA/FAG 1311TVHC3

About this product

A FAG self-aligning ball bearing (model 1311-TVH-C3) with a 55 mm bore diameter, 120 mm outside diameter, and 29 mm width, sold as a single unit. The bearing features two rows of balls in a cylindrical bore design with open sealing, and is manufactured from steel. It is rated for a basic dynamic radial load of 52,000 N and a static radial load of 17,900 N, with a reference rotation speed of 5,800 r/min and maximum safe speed of 6,100 r/min. Operating temperature range is −30 °C to 120 °C. The bearing incorporates radial internal clearance code C3 and is designed for applications involving considerable shaft deflection or alignment errors, including conveyor belts and steel production plants. The unit weighs approximately 1.567 kg and measures 130 mm in length and width by 35 mm in height when packaged. EAN 4012801159456.
