£53.35
excl. VAT
£64.02 incl. VAT
£64.02
incl. VAT
£53.35 excl. VAT
In stock
Expected to ship on Monday 21 September
Product details
| Application range | In a closed environment with grease and oil, Wheel shafts, Gearbox, Axial piston pumps, Planetary gear, Rear wheel rockers |
|---|---|
| Basic radial load dynamic | 154000 N |
| Basic radial load static | 193000 N |
| Bearing model type | Tapered roller bearings |
| dInside diameter | 45 mm |
| DOutside diameter | 100 mm |
| Inner ring width | 36 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 7300 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | 32309-A |
| Outer ring width | 30 mm |
| Properties | Absorb high radial and one-sided loads. |
| Ref rotation speed | 4100 r/min |
| Rows number | 1 |
| Sealing | Open |
| TWidth | 38.25 mm |
| Unit | Each |
| Weight | 1.439 kg |
Logistics
| EAN | 4012801047234 |
|---|---|
| Unit of measure | EA |
| Weight | 1445 g |
| Dimensions | 105 × 105 × 45 mm |
| Dangerous goods | No |
