£291.93
excl. VAT
£350.32 incl. VAT
£350.32
incl. VAT
£291.93 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Application range | Forklift attachment, Motion systems, Transport systems |
|---|---|
| Basic axial load dynamic | 3 N |
| Basic radial load dynamic | 8 N |
| Benefits | Roller and rails have a long service life, No separate axial rollers required |
| Consists of | Combination rollers with welded-on flange, Grease filling with consistency 3 |
| Details | Effective distribution of occurring, radial and axial loads, Radial and axial rollers combined in a single roller |
| Inner ring width | 29 mm |
| Outside diameter | 77.7 mm |
| Properties | Outer rings in alloy steel (20MnCr5) and hardened to 60+2 HRc, Weld-on hinge pins from C10 (material number 1.0301) |
| Stub diameter | 40 mm |
| Technical info | Types 53 to 55: rubber ring as a seal on the radial and axial roller, Types 56 to 63: metal labyrinth seal on the radial roller, rubber ring as a seal on the axial roller |
| Unit | Each |
| Weight | 0.9 kg |
| Width | 40.7 mm |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 1870 g |
| Dimensions | 119 × 77 × 46 mm |
| Dangerous goods | No |
