Product details
| Collar diameter | 135 mm |
|---|---|
| d1Inner diameter | 125 mm |
| D1Outer diameter | 140 mm |
| Groove width | 9.5 mm |
| Long description | The ASU-T38 (38) single-lip wiper is engineered to fit metric housings, including ISO 6195A standard sizes. Its precisely designed wiping lip maintains firm contact with the piston rod, effectively removing heavy contaminants such as mud and ice to protect your hydraulic system. Featuring an outer crush lip, the scraper ensures a secure interference fit within the housing, preventing contaminants from entering the groove and damaging internal components. |
| Material wiper seal | Polyester |
| Max. sliding speed | 4 m/s |
| Max. working temperature | 120 °C |
| Min. working temperature | -40 °C |
| Product details | Material : Abrasion-resistant polyester, Compatible with split housings, Most sizes can be carefully installed in blind housings, Designed with an additional sealing lip and ribs, Secure fit with reliable sealing, Built for demanding environments, Highly flexible, Excellent wear resistance, Effective dirt removal |
| Total width | 14 mm |
| Type | Rod wiper |
| Type code | ASU-T38 (38) |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 33 g |
| Dimensions | 142 × 142 × 13 mm |
| Dangerous goods | No |
