£24.05
excl. VAT
£28.86 incl. VAT
£28.86
incl. VAT
£24.05 excl. VAT
In stock
Expected to ship on Thursday 24 September
Product details
| Application range | Construction machines, Forestry machinery, Agricultural machinery, Mechanical engineering |
|---|---|
| Belt width | 13 mm |
| Bore diameter | 10 mm |
| BWorking width | 20 mm |
| Contains spokes | No |
| Designed for belt type | V-Belt |
| Designed for V-belt profile | A, SPA, AVX13 |
| dMax. bore diameter | 30 mm |
| Hub diameter | 50 mm |
| LHub width | 34 mm |
| Lock type | n/a |
| Material | Cast iron |
| Max. speed | 30 m/s |
| Number of grooves | 1 |
| OPulley outside diameter | 105.5 mm |
| PPitch diameter | 100 mm |
| Pulley type | 1 |
| Technical info | Hub bore, keyway and tapped hole are optional, Recommended minimum diameter of the v-belt pulley:, For VB13 - 71 mm, For SPA - 90 mm, For XPA - 71 mm |
| Unit | Each |
Logistics
| EAN | 8719774920057 |
|---|---|
| Unit of measure | EA |
| Weight | 1295 g |
| Dimensions | 116 × 115 × 54 mm |
| Dangerous goods | No |
