£161.23
excl. VAT
£193.48 incl. VAT
£193.48
incl. VAT
£161.23 excl. VAT
Free shipping
In stock
Expected to ship on Friday 18 September
Product details
| Application range | Construction machines, Forestry machinery, Agricultural machinery, Mechanical engineering |
|---|---|
| Belt width | 22 mm |
| Bore diameter | 20 mm |
| BWorking width | 34 mm |
| Contains spokes | Yes |
| Designed for belt type | V-Belt |
| Designed for V-belt profile | C, SPC |
| dMax. bore diameter | 54 mm |
| Hub diameter | 90 mm |
| LHub width | 50 mm |
| Lock type | n/a |
| Material | Cast iron |
| Max. speed | 30 m/s |
| Number of grooves | 1 |
| OPulley outside diameter | 289.6 mm |
| PPitch diameter | 280 mm |
| Pulley type | 3 |
| Technical info | Hub bore, keyway and tapped hole are optional, Recommended minimum diameter of the v-belt pulley:, For VB22 - 180 mm, For SPC - 224 mm, For XPC - 180 mm |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 9842 g |
| Dimensions | 300 × 300 × 33 mm |
| Dangerous goods | No |
