£8.34
excl. VAT
£10.01 incl. VAT
£10.01
incl. VAT
£8.34 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Article compression class | PN 16 |
|---|---|
| Capped | Yes |
| Chamfered | No |
| Diffusion-proof | No |
| DIN standard | 8063 |
| Expansion coefficient | 0.1 mm/(m.K) |
| Flexible | Yes |
| Inside diameter | 13.6 mm |
| ISO standard | 727 |
| Lambda value | 0.2 W/(m.K) |
| Length | 4 m |
| Manufacturer Product ID | 5020201004 |
| Material | PVC |
| Max. operating pressure at max. medium temperature | 0.5 BAR |
| Max working pressure | 16 BAR |
| Outside diameter | 16 mm |
| Pipe colour | Grey |
| Product details | UV-resistant tube, PVC pipes faded by sunlight are also pressure-stable and safe to use, PVC-U fittings are not suitable for compressed air lines!, With DVGW, CSTB and IPP certification., KIWA approved., This PVC pipes are produced according to EN1452 norm. |
| RAL-number pipe | 7300 |
| Standard Dimension Ratio (SDR) | 14 |
| Unit | Each |
| Wall thickness | 1.5 mm |
| Water content | 0.1 l/min |
| With heating cable | No |
| With thermal insulation | No |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 500 g |
| Dimensions | 4000 × 16 × 16 mm |
| Dangerous goods | No |
