£568.54
excl. VAT
£682.25 incl. VAT
£682.25
incl. VAT
£568.54 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Cable length | 1500 mm |
|---|---|
| Colour | Black |
| Current | 7.9 A |
| Distance of mounting points | 342 mm |
| Duty cycle | 10 % |
| Eye diameter | 10.1 mm |
| Insulation class | 65 |
| Long description | The LA28 linear actuator is a powerful, low-noise and smooth-running actuator ideally suited for many applications in agriculture, industrial automation or healthcare. |
| Max. pull force | 1500 N |
| Max. push force | 1500 N |
| Non load speed | 28.9 mm/s |
| On load speed | 11.7 mm/s |
| Operating temperature | 5-40 °C |
| Product details | Consists of an impact-resistant plastic housing, With a 2.3m cable with a 6.3mm jack, Increased self-locking capability for LA28 actuators with a 6 or 9mm pitch, Compatible with LINAK control boxes, Offers protection class IP51, Ambient temperature from +5°C to +40°C, Load cycle maximum 10% or two minutes and 18 minutes rest |
| Pros | Easy installation, Quiet operation |
| Stroke | 150 mm |
| Unit | Each |
| Voltage | 12 V |
| Weight | 1.7 kg |
Compatible accessories
Parts and components that work with this product.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | — |
| Dimensions | — |
| Dangerous goods | No |
