Product details
| Built-in pressure gauge | No |
|---|---|
| Capacity | 37.8 l/min |
| Connection length | 60 mm |
| Displacement per stroke | 70 cm³ |
| Includes | Tank, Piston pump, Pressure safety, Three-way valve |
| Length | 550 mm |
| Long description | MTH piston pumps with tank are suitable for short-term use with single-acting consumers. They are applicable wherever a higher hydraulic power requirement is needed than what the tractor can deliver. These pumps are ideally suited to agricultural trailers, such as for driving tipper cylinders, hook arms, and similar applications. |
| Max. delivery pressure | 260 BAR |
| Outside diameter | 25 mm |
| Product details | Fully made of steel, Drive via right-rotating tractor PTO, Oil quantity adjustable via PTO speed, Limited duty cycle, Maximum working pressure: 260 bar, Maximum speed: 540 rpm, Cylindrical drive shaft, PTO adapter for 25 mm shaft: 671020KR, PTO adapter for 35 mm shaft: 671018KR |
| Pros | Compact construction type, Wide range of applications |
| Reservoir capacity | 55 l |
| Reservoir material | Steel |
| Unit | Each |
| Weight | 34 kg |
| Width | 315 mm |
| With hose and couplings | No |
| With reservoir | Yes |
| Working type | Single acting |
Compatible accessories
Parts and components that work with this product.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 34000 g |
| Dimensions | 650 × 310 × 310 mm |
| Dangerous goods | No |
