£7.10
excl. VAT
£8.52 incl. VAT
£8.52
incl. VAT
£7.10 excl. VAT
In stock
Expected to ship on Thursday 24 September
Product details
| Connection 1, thread diameter | 1/8 Inch |
|---|---|
| Connection 1, thread type | NPT |
| Connection 1, type | Thread |
| Connection 2, centre to end distance | 20 mm |
| Connection 2, diameter | 6 mm |
| Connection 2, thread diameter | M12 |
| Connection 2, thread pitch | 1.50 mm |
| Connection 2, thread type | Metric |
| Connection 2, type | Thread |
| Connection 2, type - male/female | Female |
| Connection 2, wrench/spanner size | 12.0 mm |
| Connection no 1 center to end distance | 12 mm |
| Connection no 1 diameter | 6 mm |
| Connection no 1 thread length | 9.9 mm |
| Connection no 1 wrench size | 14.0 mm |
| DIN standard | 2401, 2353, 228, 3852 |
| Includes | Coupling, Without cutting ring and nut |
| Inside diameter | 4 mm |
| ISO standard | 228 |
| Max working pressure | 315 BAR |
| Product details | Bend 90°, Screw-in side: NPT, Metric cutting ring fitting, Stainless steel: AISI 316 ti, Temperature range: -60°C to +400°C, When fitting stainless steel parts, grease the threads with ceramic, Teflon or graphite grease |
| Pros | High corrosion resistance, Resistant to chemicals, Suitable for extreme temperatures, Food-safe, Durable |
| Series connection 1 | 6L |
| Shape | Elbow 90° |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 22 g |
| Dimensions | 30 × 28 × 16 mm |
| Dangerous goods | No |
