£197.92
excl. VAT
£237.50 incl. VAT
£237.50
incl. VAT
£197.92 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
About this product
A SKF 2213ETN9C3 self-aligning ball bearing with a 65 mm bore, 120 mm outside diameter, and 31 mm width, supplied as a single piece. The bearing features a double-row self-adjusting design with a cylindrical bore and inner ring, rated for a basic radial dynamic load of 57,200 N and static load of 20,000 N. It operates at a reference speed of 10,000 r/min with a limiting speed of 116.7 r/s, and is constructed from steel with an open (unsealed) design. The radial internal clearance is rated C3, and the bearing is not regreasable. This bearing is suitable for applications involving shaft deflection or alignment errors, such as conveyor belts and steel production plant equipment. The bearing weighs 1.391 kg and carries EAN 7316577056467.
Product details
| Application range | Bearing design with considerable shaft deflection or alignment errors, Conveyor belts, Plants for steel production |
|---|---|
| Basic radial load dynamic | 57200 N |
| Basic radial load static | 20000 N |
| Bearing model type | Self-aligning ball bearings |
| Bore type | Cylindrical |
| BWidth | 31 mm |
| Contact angle | 9.21 ° |
| dInside diameter | 65 mm |
| DOutside diameter | 120 mm |
| Inner ring shape | Cylindrical |
| Limiting speed | 116.7 r/s |
| Material | Steel |
| Original number equivalent | 2213ETN9C3 |
| Properties | Self-adjusting roller bearing, Double row |
| Radial internal clearance code | C3 |
| Ref rotation speed | 10000 r/min |
| Regreasable | No |
| Rows number | 2 |
| Sealing | Open |
| Unit | Each |
| Weight | 1.391 kg |
Logistics
| EAN | 7316577056467 |
|---|---|
| Unit of measure | EA |
| Weight | 1436 g |
| Dimensions | 165 × 160 × 66 mm |
| Dangerous goods | No |
