Product details
| Flange connection type | DIN PN10 - UNI EN 1092-1 |
|---|---|
| Flange mounting bolts/holes circle diameter | 240 mm |
| Flange mounting bolts/holes distance | 212 mm |
| Flange outside diameter | 265 mm |
| Housing material | Cast iron GG25 |
| Max medium temperature | 100 °C |
| Max working pressure | 10 BAR |
| Passage hole centre to wheel distance | 440 mm |
| Passage hole nominal diameter | 6 Inch |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | — |
| Dimensions | — |
| Dangerous goods | No |
