Product details
| Flange connection type | DIN PN10 - UNI EN 1092-1 |
|---|---|
| Flange mounting bolts/holes circle diameter | 295 mm |
| Flange mounting bolts/holes distance | 268 mm |
| Flange outside diameter | 320 mm |
| Housing material | Cast iron GG25 |
| Max medium temperature | 100 °C |
| Max working pressure | 10 BAR |
| Passage hole centre to wheel distance | 535 mm |
| Passage hole nominal diameter | 8 Inch |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 78000 g |
| Dimensions | 710 × 350 × 240 mm |
| Dangerous goods | No |
