Temperature sensor, passive, PT100 400 mm TF54PT100400

Name: Temperature sensor, passive, PT100 400 mm
SKU: BPA000374348
Price: 266.51 GBP
Availability: BackOrder

£222.09 excl. VAT

£266.51 incl. VAT

£222.09 excl. VAT

Free shipping

Out of stock — Backorder available

Usually ships within 3–8 weeks.

Policy information

Returns

14-day returns with a free prepaid label. Refunds within 5 working days.

Returns policy

Warranty

12 months from delivery — repair, replacement or refund.

Warranty terms

Delivery

Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.

Delivery information

Secure payment

3D Secure card checkout — we never store your card details.

Product details

Includes	Thermostat, Immersion protection tube type THV to be ordered separately
Insert length	400 mm
Long description	Resistance thermometer TF54 with straight protective tube, connection head made of aluminium. To be used for measuring temperatures in liquid and gaseous media in pipes, tanks or reservoirs.
Number of NC contacts	1
Number of NO contacts	1
Product details	TF54 Pt100 150mm Temperature sensor passive, Aluminium connection head, Liquid temperature : -35°C to +180°C, Sensors / Output: PT100, Connection type: 2-wire connection, Housing: aluminium, ambient temperature -20 / +100ºC - 20x1.5, Electrical connection: 0.14 - 2.5mm², screw connection on ceramic base, Protection class: III (according to EN 60 730), Protection class: IP 54 (according to EN 60529), Amperage at 230V : 15A, Amperage at 400V : 10A, Amperage at 440V : 8A
Pros	Easy assembly with clips, Easy adjustment with screwdriver
Protection class IP	55
Unit	Each

Logistics

EAN	4251325607498
Unit of measure	EA
Weight	325 g
Dimensions	470 × 81 × 81 mm
Dangerous goods	No
