£1.76
excl. VAT
£2.11 incl. VAT
£2.11
incl. VAT
£1.76 excl. VAT
In stock
Expected to ship on Tuesday 22 September
Product details
| Angle | 90 ° |
|---|---|
| Application range | PVC-U fittings are not suitable for compressed air lines! |
| Connection 1, thread type | BSP |
| Connection 1, type | Thread |
| Connection 1, type - male/female | Female |
| Connection 2, diameter | 3/4 Inch |
| Connection 2, thread type | BSP |
| Connection 2, type | Thread |
| Connection 2, type - male/female | Female |
| Connection no 1 diameter | 3/4 Inch |
| Connection no 1 length | 20 mm |
| EN Standard | 1452-3 |
| ISO standard | 1452-3, 228 |
| Material | PVC-U |
| Max working pressure | 16 BAR |
| Properties | Visual top quality, Excellent fit, Strengthening in the neck radius, Position marks on the product, Products tested at 4.2x nominal pressure, The tolerances, pressure resistance and visual quality meet the highest requirements in the market |
| Shape | Elbow |
| Unit | Each |
Logistics
| EAN | 8717284019438 |
|---|---|
| Unit of measure | EA |
| Weight | 29 g |
| Dimensions | 55 × 55 × 35 mm |
| Dangerous goods | No |
