£41.77
excl. VAT
£50.12 incl. VAT
£50.12
incl. VAT
£41.77 excl. VAT
In stock
Expected to ship on Friday 2 October
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| Connection 1, thread diameter | 3/4 Inch |
|---|---|
| Connection 1, thread type | BSP |
| Connection 1, type | Banjo |
| Connection 1, type - male/female | Male |
| Connection 2, diameter | 20 mm |
| Connection 2, length | 48 mm |
| Connection 2, thread diameter | M30 |
| Connection 2, thread pitch | 2.00 mm |
| Connection 2, thread type | Metric |
| Connection 2, type | Banjo |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 36.0 mm |
| Connection no 1 center to end distance | 49 mm |
| Connection no 1 diameter | 18 mm |
| Connection no 1 threads per inch | 14 |
| DIN standard | 2401, 2353, 228, 3852 |
| Inside diameter | 15 mm, 16 mm |
| ISO standard | 228 |
| KConnection no 1 thread length | 16 mm |
| L1Connection 2, centre to end distance | 27.5 mm |
| Max. tightening torque | 250 N·m |
| Max working pressure | 315 BAR |
| Product details | Multiple corrosion resistance, Adjustable direction, The adjusted direction is fixed by lock nut |
| S3Connection no 1 wrench size | 36.0 mm |
| Seal material | Metal |
| Series connection 1 | 20S |
| Shape | Elbow 90° |
| Surface treatment | Nickel, Zinc |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 386 g |
| Dimensions | 70 × 55 × 42 mm |
| Dangerous goods | No |
