Product details
| Connection 1, thread diameter | 1-1/4 Inch |
|---|---|
| Connection 1, thread pitch | 2.00 mm |
| Connection 1, thread type | BSP |
| Connection 1, type | Cutting ring |
| Connection 1, type - male/female | Male |
| Connection 2, centre to end distance | 35.5 mm |
| Connection 2, length | 70 mm |
| Connection 2, thread diameter | 1-1/4 Inch |
| Connection 2, threads per inch | 11 |
| Connection 2, thread type | BSP |
| Connection 2, type | Banjo |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 55.0 mm |
| Connection no 1 center to end distance | 63 mm |
| Connection no 1 diameter | 28 mm |
| DIN standard | 2401, 2353, 228, 3852 |
| Inside diameter | 24 mm, 25 mm |
| ISO standard | 228 |
| L1Connection no 1 thread length | 20 mm |
| Max. tightening torque | 600 N·m |
| Max working pressure | 250 BAR |
| Product details | Multiple corrosion resistance, Adjustable direction, The adjusted direction is fixed by lock nut |
| S3Connection no 1 wrench size | 50.0 mm |
| Seal material | Nitrile rubber [NBR] |
| Series connection 1 | 30S |
| Shape | Elbow 90° |
| Surface treatment | Nickel, Zinc |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 1263 g |
| Dimensions | 105 × 85 × 60 mm |
| Dangerous goods | No |
