Roll over image to zoom in · Click to see full view
£16.30
excl. VAT
£19.56 incl. VAT
£19.56
incl. VAT
£16.30 excl. VAT
In stock
Expected to ship on Friday 2 October
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| Body height | 24 mm |
|---|---|
| Connection 1, thread diameter | M26 |
| Connection 1, thread pitch | 1.50 mm |
| Connection 1, thread type | NPT |
| Connection 1, type - male/female | Female |
| Connection 2, thread diameter | M22 |
| Connection 2, thread pitch | 1.50 mm |
| Connection 2, thread type | Metric |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 24.0 mm |
| Connection no 1 thread length | 14 mm |
| Connection no 1 wrench size | 32.0 mm |
| d2Connection no 1 diameter | 18 mm |
| DIN standard | 2401, 2353, 228, 3852 |
| Inside diameter | 14 mm, 15 mm |
| ISO standard | 228 |
| L2Connection 2, centre to end distance | 23.5 mm |
| L3Connection no 1 center to end distance | 26.5 mm |
| Max working pressure | 315 BAR |
| Product details | Direct connection with a metric hose gland or pre-mounted coupling, Multiple corrosion resistance |
| Pros | Reduced risk of leakage |
| Series connection 1 | 18L |
| Shape | Elbow 90° |
| Surface treatment | Nickel, Zinc |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 154 g |
| Dimensions | 47 × 42 × 25 mm |
| Dangerous goods | No |
