Roll over image to zoom in · Click to see full view
£3.05
excl. VAT
£3.66 incl. VAT
£3.66
incl. VAT
£3.05 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| Connection 1, thread diameter | M20 |
|---|---|
| Connection 1, thread pitch | 1.50 mm |
| Connection 1, thread type | Metric |
| Connection 1, type | Cutting ring |
| Connection 1, type - male/female | Male |
| Connection 2, diameter | 17 mm |
| Connection 2, thread type | Metric |
| Connection 2, type | Cutting ring |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 24.0 mm |
| Connection no 1 diameter | 12 mm |
| DIN standard | 2401 |
| dyInside diameter | 8 mm |
| Includes | Coupling, Excluding cutting ring, Excluding gland nut |
| Material | Steel |
| Max working pressure | 630 BAR |
| Product details | Direct connection with a metric hose gland or pre-mounted coupling, Multiple corrosion resistance, Weld-on coupling, Available in stainless steel on request |
| Pros | Reduced risk of leakage |
| Series connection 1 | 12S |
| Shape | Straight |
| Surface treatment | Zinc, Nickel-plated |
| SW1Connection no 1 wrench size | 22.0 mm |
| Total length | 32 mm |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 56 g |
| Dimensions | 32 × 23 × 21 mm |
| Dangerous goods | No |
