£1,502.57
excl. VAT
£1,803.08 incl. VAT
£1,803.08
incl. VAT
£1,502.57 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Brake release port thread diameter | 1/4 Inch |
|---|---|
| Brake release port thread type | G |
| Displacement | 200 cm³/rev |
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange code | SAE-A |
| Flange shape | Oval |
| Housing length | 259.2 mm |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Max. continous working pressure | 110 BAR |
| Max continuous torque | 300 N·m |
| Max. flow rate | 60 l/min |
| Max intermittend working pressure | 140 BAR |
| Max. power | 8 kW |
| Max pressure peak | 225 BAR |
| Max rotation speed | 300 r/min |
| Min rotation speed | 5 r/min |
| Number of mounting holes | 2 |
| Product details | Orbital motors with integrated passive parking brake, Not for use as dynamic brake, Brake motors must always have a drain line, Brake release pressure must be at least 21 bar, and is the difference between the pressure in the brake release line and the pressure in the drain line |
| Rotor length | 34.8 mm |
| Sealing type | Standard |
| Shaft diameter | 25 mm |
| Shaft type | Straight parallel |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 13402 g |
| Dimensions | 441 × 168 × 151 mm |
| Dangerous goods | No |
