£935.06
excl. VAT
£1,122.07 incl. VAT
£1,122.07
incl. VAT
£935.06 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 100 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange shape | Standard |
| Housing length | 171.8 mm |
| Long description | Orbital motors are distinguished by their compact construction, large axial, radial shaft loads and high starting torque |
| Main port center to front flange distance | 127.5 mm |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Main second port center to front flange distance | 149.5 mm |
| Max. continous working pressure | 210 BAR |
| Max continuous torque | 305 N·m |
| Max. flow rate | 75 l/min |
| Max intermittend working pressure | 275 BAR |
| Max. power | 18 kW |
| Max pressure peak | 295 BAR |
| Max rotation speed | 750 r/min |
| Min rotation speed | 10 r/min |
| Number of mounting holes | 4 |
| Original number equivalent | 151F0561 |
| Product details | Particularly suitable for continuous use in tough conditions, High continuous operating pressure, Very consistent operation at low speeds, Frequent reversing possible, High efficiency, Excellent start-up properties, Very high permissible radial load on the shaft is possible |
| Sealing type | Standard |
| Shaft diameter | 35 mm |
| Shaft number of teeth | 6 |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
OMP9WP
Unbranded Welding plate OMP OMR OMS OMP9WP
£23.61 excl.
£28.33 incl.
OMS9AFDPTO
White Gasket set 151F0117 OMS9AFDPTO
£91.07 excl.
£109.28 incl.
VADDF10001
Walvoil Relief val 10 A 08 OMS A 1/2" VADDF10001
£125.49 excl.
£150.59 incl.
VANT12OMS
Walvoil Check valve VANT T 12-OMS VANT12OMS
£71.36 excl.
£85.63 incl.
VODLSCAF10001
Walvoil Counterbalance A-08-OMS 1/2BSP VODLSCAF10001
£323.75 excl.
£388.50 incl.
VODLSCF10001
Walvoil Counterbal A-08-OMS-A-4 1/2" VODLSCF10001
£306.14 excl.
£367.37 incl.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 10680 g |
| Dimensions | 407 × 183 × 174 mm |
| Dangerous goods | No |
