£785.25
excl. VAT
£942.30 incl. VAT
£942.30
incl. VAT
£785.25 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 375 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange code | A2 |
| Flange diameter | 106.4 mm |
| Flange shape | Oval |
| Housing length | 179.8 mm |
| Long description | Orbital motor offers compact construction and simple mounting. High torque and shaft load, because of shorter distance from mounting flange to the point of load application. |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Max. continous working pressure | 80 BAR |
| Max continuous torque | 390 N·m |
| Max. flow rate | 60 l/min |
| Max intermittend working pressure | 115 BAR |
| Max. power | 5.6 kW |
| Max pressure peak | 130 BAR |
| Max rotation speed | 165 r/min |
| Min rotation speed | 5 r/min |
| Min. starting pressure | 7 BAR |
| Min. starting torque | 335 N·m |
| Mounting holes circle diameter | 82.5 mm |
| Number of mounting holes | 2 |
| Original number equivalent | 1510428 |
| Port position | Side |
| Product details | Flexibility thanks to a variety of shaft and flange combinations, Well suited for frequent reversing operations, Highly efficient, High continuous pressure, Long service life |
| Rotor length | 54.8 mm |
| Sealing type | High pressure |
| Shaft diameter | 1 Inch |
| Shaft number of teeth | 6 |
| Shaft type | Splined |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 9414 g |
| Dimensions | 310 × 180 × 175 mm |
| Dangerous goods | No |
