£430.84
excl. VAT
£517.01 incl. VAT
£517.01
incl. VAT
£430.84 excl. VAT
Free shipping
In stock
Expected to ship on Friday 18 September
Product details
| Application range | Tedders, Rakes, Silo spreaders |
|---|---|
| Benefits | Audible signal on overload, Pulsating power transmission in the event of slipping |
| Clutch type code | LN4 |
| Connection locking type | Collar lock |
| Cross cap diameter | 27 mm |
| Cross length | 74.6 mm |
| Details | If slipping through, the clutch begins to rattle, Limits the torque in the event of an overload |
| Inside connection diamter inch and splines | 1.3/8-6 |
| Long description | Star ratchet / radial pin clutches, series LN-5 |
| Max static torque | 1200 N·m |
| Mounting holes circle diameter | 37 mm |
| Original number equivalent | 60B4E4803R |
| Outside diameter | 96 mm |
| Properties | 2 directions of rotation, Shocks and vibrations |
| Shaft size code | 4, G4, S4 |
| Suitable for machine/vehicle brand | n/a |
| Technical info | Force transmission using cam and springs |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 6052 g |
| Dimensions | 219 × 103 × 103 mm |
| Dangerous goods | No |
You might also like
BPA000066909
Bondioli&Pavesi Guard cone GLOBAL for G5/7/8 219051001
£16.33 excl.
£19.60 incl.
In stock
Expected to ship on Friday 18 September
Free shipping
BPA000066926
Bondioli&Pavesi Guard cone WW-80° S8/H8 2190L0121
