£864.63
excl. VAT
£1,037.56 incl. VAT
£1,037.56
incl. VAT
£864.63 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Application range | Big baler, Wood shredders, Loader wagons, Spreaders, Fertiliser mixer |
|---|---|
| Attachment tractor side | Quick disconnect yoke |
| Benefits | Low slide resistance, Low wear, Longer service life |
| Clutch type code | LB |
| Connection outside diameter machine side inch and splines | 1.3/4-6 |
| Connection outside diameter tractor side inch and splines | 1.3/8-6 |
| Consists of | Pto shaft with guard tube, Declaration of conformity, Instruction manual |
| Cross joint bush diameter by machine side | 34.9 mm |
| Cross joint bush diameter by tractor side | 34.9 mm |
| Cross joint length by machine side | 106 mm |
| Cross joint length by tractor side | 106 mm |
| Details | Square profile tube for maximum torsional stiffness, Torque is evenly distributed over the wide contact surfaces, Extended lubrication intervals of up to 50 hours |
| Extra info | Do not use this product at a speed of 1000 rpm. Also consult one of our product specialists for advice. |
| Inner tube profile | 12238 |
| Length | 1610 mm |
| Long description | PTO Drive Shafts - SFT, series S9 |
| Max. clutch torque | 3500 N·m |
| Max dynamic torque | 245 N·m |
| Outer tube profile | 12211 |
| Power 1000 rpm | 122 kW |
| Power 540 rpm | 81 kW |
| Properties | CE marking available |
| Size code | S9 |
| Technical info | Refer to the Bondioli & Pavesi instruction manual, Values at working angle 5° and service life 1000 hours |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 33620 g |
| Dimensions | 1900 × 200 × 200 mm |
| Dangerous goods | No |
