£677.95
excl. VAT
£813.54 incl. VAT
£813.54
incl. VAT
£677.95 excl. VAT
Free shipping
In stock
Expected to ship on Friday 18 September
Product details
| Displacement | 22.5 cm³/rev, 16 cm³/rev |
|---|---|
| Flange and back cover material | Cast iron |
| Flange code | P |
| Flange type norm | German |
| Housing material | Aluminium |
| Max. continous working pressure | 250 BAR, 250 BAR |
| Max intermittend working pressure | 210 BAR, 210 BAR |
| Max pressure peak | 220 BAR, 220 BAR |
| Max rotation speed | 3000 r/min |
| Min rotation speed | 600 r/min |
| Mounting diameter | 50 mm |
| Mounting holes horizontal distance | 60 mm |
| Mounting holes vertical distance | 60 mm |
| Number of mounting holes | 2 |
| Original number equivalent | R918C02671, 01176451, 01179086, 1175999, 0510765336, 0510765332 |
| Port position | Side |
| Pressure port bolts circle diameter | 35 mm |
| Pump group code | 2 |
| Rotation direction | Counter-clockwise (CCW) |
| Sealing material | Viton |
| Sealing type | Standard |
| Shaft cone size code | n/a |
| Shaft diameter | 16.5 mm |
| Shaft number of teeth | 9 |
| Shaft thread diameter | n/a |
| Shaft thread type | n/a |
| Shaft type | Splined 9T |
| Shaft type code | F |
| Suction port bolts circle diameter | 40 mm |
| Unit | Each |
| Weight | 5.7 kg |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 5801 g |
| Dimensions | 251 × 100 × 90 mm |
| Dangerous goods | No |
