£1,029.72
excl. VAT
£1,235.66 incl. VAT
£1,235.66
incl. VAT
£1,029.72 excl. VAT
Free shipping
In stock
Expected to ship on Thursday 24 September
Product details
| Adjustment type | Hand wheel |
|---|---|
| Connection 2, type - male/female | Female |
| Connection thread diameter | M22 |
| Connection thread pitch | 1.50 mm |
| Long description | The MTCA flow regulator divides the inlet flow into a constant flow (fixed or manually adjustable) and a residual flow. Both partial flows can be pressurized independently of each other and are protected by an adjustable pressure limiter located in the total flow. The pressure that builds up in the supply line is that of the most heavily loaded downstream device. If the constant flow is interrupted (for example when the cylinder reaches its end position), the oil is directed to the residual flow against system pressure. If the residual flow is also interrupted, the total flow is directed to the tank via port T, against the set pressure. |
| Material | Steel |
| Max. flow rate | 80 l/min |
| Max. regulated flow | 65 l/min |
| Max working pressure | 315 BAR |
| Max working temperature | 80 °C |
| Min working temperature | -20 °C |
| Product details | Maximum pressure : 315 bar, Steel housing |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 2567 g |
| Dimensions | 200 × 120 × 101 mm |
| Dangerous goods | No |
