£307.70
excl. VAT
£369.24 incl. VAT
£369.24
incl. VAT
£307.70 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Application | Telescopic |
|---|---|
| Application range | Trailer tipping cylinder, Vehicle construction |
| BOil connection length | 40 mm |
| C1Oil connection to rod end distance | 101 mm |
| CSide shaft diameter | 35 mm |
| Cylinder material | Steel S355J2+N |
| Details | Tenifer TF1 coating |
| DIN standard | 1629 |
| DOutside diameter | 80 mm |
| HMounting hole diameter - rod connection | 26 mm |
| IMounting bush outside diameter | 27 mm |
| LMin. length | 380 mm |
| Long description | Telescopic cylinders 2-stage F |
| Max. capacity at 180 bar | 5.2 t |
| Max. capacity - stage 2 | 5.2 t |
| Max. piston speed | 0.5 m/s |
| Max. working pressure | 180 BAR |
| Mounting hole center to cylinder end distance | 240 mm |
| Mounting hole diameter - cylinder connection | 40 mm |
| Mounting type - cylinder side connection | Trunnion |
| Mounting type - rod side connection | Bore |
| Number of stages | 2 |
| Oil capacity | 1.1 l |
| Piston surface roughness range | 0.05-0.15 µm |
| Properties | Unpainted, Low installation dimensions, Excellent running properties, Long service life |
| Sealing material | Polyurethane |
| Stage 1 diameter | 46 mm |
| Stage 2 diameter | 61 mm |
| Stroke | 455 mm |
| Unit | Each |
| Vickers hardness (HV) | HV5/12=500/550 |
| Weight | 14 kg |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 12540 g |
| Dimensions | 370 × 185 × 95 mm |
| Dangerous goods | No |
You might also like
Free shipping
BPA000373615
Di Natale-Bertelli Telescopic cylinder TC 3037 ball head TC3037
£715.57 excl.
£858.68 incl.
Backorder available
Usually ships within 3–8 weeks
Free shipping
BPA000373717
Di Natale-Bertelli Telescopic cylinder TC 5002 ball head TC5002
£1,679.28 excl.
£2,015.14 incl.
Backorder available
Usually ships within 3–8 weeks
Free shipping
BPA000373784
Di Natale-Bertelli Seal kit TC93041
£106.40 excl.
£127.68 incl.
In stock
Expected to ship on Tuesday 22 September
Free shipping
BPA000373664
Di Natale-Bertelli Telescopic cylinder 4033 / hole in rod TC4033F
£556.03 excl.
£667.24 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000373809
Di Natale-Bertelli Ballhead complete D55 Square TC955B
