£14.54
excl. VAT
£17.45 incl. VAT
£17.45
incl. VAT
£14.54 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Connection 1, thread diameter | 3/8 Inch |
|---|---|
| Connection 1, thread type | BSP |
| Connection 1, type | Thread |
| Connection 1, type - male/female | Male |
| Connection 2, centre to end distance | 12 mm |
| Connection 2, thread diameter | 1/4 Inch |
| Connection 2, thread type | BSP |
| Connection 2, type | Thread |
| Connection 2, type - male/female | Female |
| Connection 2, wrench/spanner size | 22.0 mm |
| Connection no 1 center to end distance | 17 mm |
| DIN standard | 228 |
| LTotal length | 36 mm |
| Material | Stainless steel AISI 316L |
| Max working pressure | 630 BAR |
| Product details | When fitting stainless steel parts, grease the threads with ceramic, Teflon or graphite grease, With WD seal |
| Seal material | Nitrile rubber [NBR] |
| Shape | Straight |
| Unit | Each |
Logistics
| EAN | 8432770152337 |
|---|---|
| Unit of measure | EA |
| Weight | 70 g |
| Dimensions | 36 × 24 × 22 mm |
| Dangerous goods | No |
