£30.14
excl. VAT
£36.17 incl. VAT
£36.17
incl. VAT
£30.14 excl. VAT
In stock
Expected to ship on Friday 18 September
Product details
| Basic radial load dynamic | 30000 N |
|---|---|
| Basic radial load static | 21200 N |
| Bearing model type | Angular contact ball bearings |
| BWidth | 23.8 mm |
| Contact angle | 30 ° |
| dInside diameter | 30 mm |
| DOutside diameter | 62 mm |
| Inside diameter of outer ring | 53.3 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 11900 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | 3206-BD-XL-TVH |
| Outside diameter of inner ring | 40.33 mm |
| Radial internal clearance code | CN |
| Ref rotation speed | 9500 r/min |
| Regreasable | Yes |
| Rows number | 2 |
| Sealing | Open |
| Surface treatment | n/a |
| Unit | Each |
Logistics
| EAN | 4064327672926 |
|---|---|
| Unit of measure | EA |
| Weight | 289 g |
| Dimensions | 67 × 67 × 30 mm |
| Dangerous goods | No |
