£80.80
excl. VAT
£96.96 incl. VAT
£96.96
incl. VAT
£80.80 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Application range | High radial loads and high speeds, Gearbox, Gearbox, Worm gear shaft, Spring plates |
|---|---|
| Basic radial load dynamic | 73000 N |
| Basic radial load static | 65000 N |
| Bearing model type | Cylindrical roller bearings |
| BWidth | 23 mm |
| Consists of | Cylindrical bearing, Inner ring NUP |
| dInside diameter | 35 mm |
| DOutside diameter | 72 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 12300 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | NUP2207-E-TVP2 |
| Properties | Outer ring with 2 fixed ribs, Inner ring with 1 fixed and 1 loose rib, Fixed bearing, to lock shaft axially in 2 directions |
| Radial internal clearance code | CN |
| Ref rotation speed | 10000 r/min |
| Rows number | 1 |
| Sealing | Open |
| Unit | Each |
| Weight | 0.385 kg |
Logistics
| EAN | 4012801021739 |
|---|---|
| Unit of measure | EA |
| Weight | 427 g |
| Dimensions | 76 × 75 × 27 mm |
| Dangerous goods | No |
You might also like
BPA000153644
FAG Deep groove ball bearing 35x80x21mm INA/FAG 6307ZZC3
£15.36 excl.
£18.43 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000277883
FAG Locating ring FRM(FRB) FRM909
£13.61 excl.
£16.33 incl.
In stock
Expected to ship on Tuesday 22 September
Free shipping
BPA000067629
FAG Spherical roller bearing 75x160x37mm 21315K
£301.16 excl.
£361.39 incl.
Backorder available
Usually ships within 3–8 weeks
Free shipping
BPA000168786
FAG Angular contact ball bearing 7316BTVP
£427.56 excl.
£513.07 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000380807
FAG Housing unit UCT203J7
£32.85 excl.
£39.42 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000155020
FAG Deep groove ball bearing 40x62x12mm INA/FAG 61908
£26.01 excl.
£31.21 incl.
In stock
Expected to ship on Tuesday 22 September
Recently viewed
BPA000041642
Kramp Spring lock washer M16x27.4x3.5mm, Steel Zinc-plated DIN 127b 127B16
£0.06 excl.
£0.07 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000077160
Kramp Oil seal 25x38x10mm type:CC DIN 3760 1x 253810CCP001
£1.51 excl.
£1.81 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000201221
Kramp Oil seal 95x130x13mm type:CC DIN 3760 1x 9513013CCP001
£8.07 excl.
£9.68 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000209232
Kramp Hexagon Lock Nut DIN985 M30x1.50 steel zinc-Plated Class 10 985301510
£12.10 excl.
£14.52 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000202182
Kramp Hexagon head bolt DIN933 M8x40 steel zinc-plated 10.9 933840109
£0.36 excl.
£0.43 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000116523
Kramp Eye bolt DIN444B M20x110 steel zinc-plated 4.6 444B20110
£9.68 excl.
£11.62 incl.
In stock
Expected to ship on Tuesday 22 September
BPA000144452
Kramp Wood screw 12x260mm, 19mm hex head, DIN 571 57112260P025
