£61.66
excl. VAT
£73.99 incl. VAT
£73.99
incl. VAT
£61.66 excl. VAT
In stock
Expected to ship on Tuesday 22 September
Product details
| Application range | High radial loads and high speeds, Gearbox, Gearbox, Worm gear shaft, Spring plates |
|---|---|
| Basic radial load dynamic | 76000 N |
| Basic radial load static | 63000 N |
| Bearing model type | Cylindrical roller bearings |
| BWidth | 21 mm |
| Consists of | Cylindrical bearing, Inner ring NU |
| dInside diameter | 35 mm |
| DOutside diameter | 80 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 12600 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | NU307-E-TVP2 |
| Properties | Outer ring with 2 fixed ribs, Inner ring without rib, Axial displacement of shaft with regard to housing in 2 directions |
| Radial internal clearance code | CN |
| Ref rotation speed | 9000 r/min |
| Rows number | 1 |
| Sealing | Open |
| Unit | Each |
| Weight | 0.047 kg |
Logistics
| EAN | 4012801021456 |
|---|---|
| Unit of measure | EA |
| Weight | 482 g |
| Dimensions | 83 × 83 × 25 mm |
| Dangerous goods | No |
You might also like
BPA000150249
FAG Deep groove ball bearing 40x68x15mm INA/FAG 60082RSC4
£18.59 excl.
£22.31 incl.
In stock
Expected to ship on Tuesday 22 September
Free shipping
BPA000085972
FAG Angular ball bearings in 2rows 3211BDTVHC3
£141.56 excl.
£169.87 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000150856
FAG Deep groove ball bearing 95x145x24mm INA/FAG 6019C3FAG
£87.29 excl.
£104.75 incl.
Backorder available
Usually ships within 3–8 weeks
BPA000380758
FAG Housing unit UCP UCP209
