£64.68
excl. VAT
£77.62 incl. VAT
£77.62
incl. VAT
£64.68 excl. VAT
In stock
Expected to ship on Tuesday 22 September
Product details
| Application range | High radial loads and high speeds, Gearbox, Gearbox, Worm gear shaft, Spring plates |
|---|---|
| Basic radial load dynamic | 72000 N |
| Basic radial load static | 63000 N |
| Bearing model type | Cylindrical roller bearings |
| BWidth | 19 mm |
| Consists of | Cylindrical bearing, Inner ring NJ |
| dInside diameter | 45 mm |
| DOutside diameter | 85 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 10200 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | NJ209-E-TVP2 |
| Properties | Outer ring with 2 fixed ribs, Inner ring with 1 rib, Shaft can be closed axially in 1 direction |
| Radial internal clearance code | CN |
| Ref rotation speed | 8500 r/min |
| Rows number | 1 |
| Sealing | Open |
| Unit | Each |
| Weight | 0.432 kg |
Logistics
| EAN | 4012801020718 |
|---|---|
| Unit of measure | EA |
| Weight | 444 g |
| Dimensions | 93 × 92 × 22 mm |
| Dangerous goods | No |
