£47.89
excl. VAT
£57.47 incl. VAT
£57.47
incl. VAT
£47.89 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Application range | High radial loads and high speeds, Gearbox, Gearbox, Worm gear shaft, Spring plates |
|---|---|
| Basic radial load dynamic | 15100 N |
| Basic radial load static | 10400 N |
| Bearing model type | Cylindrical roller bearings |
| BWidth | 11 mm |
| Consists of | Cylindrical bearing, Inner ring NJ |
| dInside diameter | 15 mm |
| DOutside diameter | 35 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 31000 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -30 °C |
| Original number equivalent | NJ202-E-XL-TVP2 |
| Properties | Outer ring with 2 fixed ribs, Inner ring with 1 rib, Shaft can be closed axially in 1 direction |
| Radial internal clearance code | CN |
| Ref rotation speed | 17900 r/min |
| Rows number | 1 |
| Sealing | n/a |
| Unit | Each |
Logistics
| EAN | 4012801176477 |
|---|---|
| Unit of measure | EA |
| Weight | 51 g |
| Dimensions | 47 × 44 × 12 mm |
| Dangerous goods | No |
