£169.36
excl. VAT
£203.23 incl. VAT
£203.23
incl. VAT
£169.36 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Application range | Construction machines, Forestry machinery, Agricultural machinery, Mechanical engineering |
|---|---|
| Belt width | 17 mm |
| Benefits | Can be used with different shaft diameters, Fast and simple to assemble and dismantle |
| Consists of | V-belt pulley, No taperlock adjustment bush supplied |
| Designed for belt type | V-Belt |
| Designed for V-belt profile | B, SPB |
| Details | With taperlock bore |
| FWorking width | 82 mm |
| Hub width | 51 mm |
| JChamber diameter | 193 mm |
| KHub offset 1 | 15.5 mm |
| Lock type | 3020 |
| Material | Cast iron |
| Max. bore diameter | 75 mm |
| Max. speed | 30 m/s |
| MHub offset 2 | 15.5 mm |
| Number of grooves | 4 |
| OPulley outside diameter | 243 mm |
| PPitch diameter | 236 mm |
| Pulley type | 3 |
| Technical info | Recommended minimum diameter of the v-belt pulley:, For VB17 - 112 mm, For SPB - 140 mm, For XPB - 112 mm |
| Unit | Each |
Logistics
| EAN | 4014486247206 |
|---|---|
| Unit of measure | EA |
| Weight | 13928 g |
| Dimensions | 245 × 245 × 91 mm |
| Dangerous goods | No |
