Roll over image to zoom in · Click to see full view
£5.36
excl. VAT
£6.43 incl. VAT
£6.43
incl. VAT
£5.36 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| dInside diameter | 45 mm |
|---|---|
| DOutside diameter | 53 mm |
| eGroove thickness | 6.3 mm |
| HWidth | 5.7 mm |
| Long description | The excellent properties of polyurethane and the asymmetrical profile make this type ideal for hydraulic applications. The excellent oil resistance, high tensile strength and wear resistance make these sleeves ideal for use as piston rod seals. |
| Material | Polyurethane |
| Max. sliding speed | 0.5 m/s |
| Max. working pressure | 400 BAR |
| Max. working temperature | 100 °C |
| Min. working temperature | -30 °C |
| Type | Rod seal |
| Type code | 605 |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 7 g |
| Dimensions | 51 × 51 × 3 mm |
| Dangerous goods | No |
