Voss Angled screw connection WES22L34NPT

Name: Angled screw connection
Brand: Voss
SKU: BPA000402355
Price: 22.80 GBP
Availability: BackOrder

£19.00 excl. VAT

£22.80 incl. VAT

£19.00 excl. VAT

Out of stock — Backorder available

Usually ships within 3–8 weeks.

Policy information

Returns

14-day returns with a free prepaid label. Refunds within 5 working days.

Returns policy

Warranty

12 months from delivery — repair, replacement or refund.

Warranty terms

Delivery

Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.

Delivery information

Secure payment

3D Secure card checkout — we never store your card details.

Product details

Body height	27 mm
Connection 1, thread diameter	3/4 Inch
Connection 1, thread type	NPT
Connection 2, centre to end distance	42 mm
Connection 2, diameter	22 mm
Connection 2, thread diameter	M30
Connection 2, thread pitch	2.00 mm
Connection 2, thread type	Metric
Connection 2, type - male/female	Female
Connection 2, wrench/spanner size	27.0 mm
Connection no 1 center to end distance	27.5 mm
Connection no 1 diameter	22 mm
DIN standard	2401, 2353, 228, 3852
Includes	without separate nut and cutting ring
Inside diameter	18 mm, 19 mm
ISO standard	228
L1Connection no 1 thread length	20.1 mm
Max. tightening torque	175 N·m
Max working pressure	160 BAR
S2Connection no 1 wrench size	36.0 mm
Series connection 1	22L
Shape	Elbow 90°
Surface treatment	Galvanised
Unit	Each

Logistics

EAN	—
Unit of measure	EA
Weight	202 g
Dimensions	55 × 50 × 28 mm
