Roll over image to zoom in · Click to see full view
£7.24
excl. VAT
£8.69 incl. VAT
£8.69
incl. VAT
£7.24 excl. VAT
In stock
Expected to ship on Monday 5 October
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| Body height | 12 mm |
|---|---|
| Connection 1, thread diameter | 1/8 Inch |
| Connection 1, thread type | BSP |
| Connection 1, type - male/female | Male |
| Connection 2, centre to end distance | 20 mm |
| Connection 2, diameter | 8 mm |
| Connection 2, thread diameter | M8 |
| Connection 2, thread pitch | 1.00 mm |
| Connection 2, thread type | Metric |
| Connection 2, type - male/female | Female |
| Connection 2, wrench/spanner size | 12.0 mm |
| Connection no 1 center to end distance | 11.5 mm |
| Connection no 1 diameter | 8 mm |
| DIN standard | 2401, 2353, 228, 3852 |
| Includes | without separate nut and cutting ring |
| Inside diameter | 6 mm |
| ISO standard | 228 |
| L1Connection no 1 thread length | 9.9 mm |
| Max. tightening torque | 15 N·m |
| Max working pressure | 100 BAR |
| S2Connection no 1 wrench size | 14.0 mm |
| Series connection 1 | 8LL |
| Shape | Elbow 90° |
| Surface treatment | Galvanised |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 29 g |
| Dimensions | 27 × 24 × 18 mm |
| Dangerous goods | No |
