Roll over image to zoom in · Click to see full view
£4.09
excl. VAT
£4.91 incl. VAT
£4.91
incl. VAT
£4.09 excl. VAT
In stock
Expected to ship on Friday 2 October
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| Body height | 33.5 mm |
|---|---|
| Connection 1, thread diameter | M26 |
| Connection 1, thread pitch | 1.50 mm |
| Connection 1, thread type | UNF |
| Connection 1, type | Cutting ring |
| Connection 1, type - male/female | Male |
| Connection 2, centre to end distance | 14 mm |
| Connection 2, thread diameter | M18 |
| Connection 2, thread pitch | 1.50 mm |
| Connection 2, thread type | Metric |
| Connection 2, type | Thread |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 32.0 mm |
| Connection no 1 center to end distance | 30.5 mm |
| Connection no 1 diameter | 18 mm |
| DIN standard | 2401, 2353, 228, 3852 |
| dxInside diameter | 12 mm |
| iConnection no 1 thread length | 12 mm |
| ISO standard | 228 |
| Max. tightening torque | 90 N·m |
| Max working pressure | 400 BAR |
| Product details | WD = Pre-assembled with flexible seal, Optimal cutting ring connection and functionality, Multiple corrosion resistance |
| Pros | Reduced risk of leakage |
| Seal material | Nitrile rubber [NBR] |
| Series connection 1 | 18L |
| Shape | Straight |
| Surface treatment | Nickel, Zinc |
| SW1Connection no 1 wrench size | 27.0 mm |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 67 g |
| Dimensions | 39 × 25 × 25 mm |
| Dangerous goods | No |
