Product details
| Body height | 26 mm |
|---|---|
| Connection 1, thread diameter | M12 |
| Connection 1, thread pitch | 1.50 mm |
| Connection 1, thread type | BSP |
| Connection 1, type | Cutting ring |
| Connection 1, type - male/female | Male |
| Connection 2, thread diameter | 1/8 Inch |
| Connection 2, threads per inch | 28 |
| Connection 2, thread type | BSP |
| Connection 2, type | Thread |
| Connection 2, type - male/female | Female |
| Connection 2, wrench/spanner size | 14.0 mm |
| Connection no 1 diameter | 6 mm |
| Connection no 1 length | 12 mm |
| Inside diameter | 30.33 mm |
| L1Connection no 1 center to end distance | 34 mm |
| L2Connection 2, centre to end distance | 19 mm |
| Max working pressure | 315 BAR |
| Product details | Direct connection with a metric hose gland or pre-mounted coupling |
| Pros | Reduced risk of leakage, Multiple corrosion resistance |
| S1Connection no 1 wrench size | 14.0 mm |
| Series connection 1 | 6L |
| Shape | Straight |
| Surface treatment | Nickel, Zinc |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 20 g |
| Dimensions | 25 × 15 × 13 mm |
| Dangerous goods | No |
