Roll over image to zoom in · Click to see full view
£2.00
excl. VAT
£2.40 incl. VAT
£2.40
incl. VAT
£2.00 excl. VAT
In stock
Expected to ship on Monday 5 October
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| ANSI standard | B1.20.1-1983. |
|---|---|
| Body height | 33.1 mm |
| Connection 1, thread diameter | 1/4 Inch |
| Connection 1, thread pitch | 1.50 mm |
| Connection 1, thread type | BSP |
| Connection 1, type | Cutting ring |
| Connection 1, type - male/female | Male |
| Connection 2, thread diameter | 1/4 Inch |
| Connection 2, threads per inch | 18 |
| Connection 2, thread type | NPT |
| Connection 2, type | Seal ring |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 17.0 mm |
| Connection no 1 diameter | 6 mm |
| DIN standard | 2353 |
| Inside diameter | 4 mm |
| KConnection no 1 thread length | 10.2 mm |
| Max. tightening torque | 35 N·m |
| Max working pressure | 630 BAR |
| Product details | 2S cutting ring |
| S1Connection no 1 wrench size | 17.0 mm |
| Series connection 1 | 15L |
| Shape | Straight |
| Surface treatment | Nickel, Zinc |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 33 g |
| Dimensions | 35 × 22 × 22 mm |
| Dangerous goods | No |
