£825.54
excl. VAT
£990.65 incl. VAT
£990.65
incl. VAT
£825.54 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 100 cm³/rev |
|---|---|
| Drain port thread diameter | 7/16 Inch |
| Drain port threads per inch | 20 |
| Drain port thread type | UNF |
| Flange shape | Standard |
| Housing length | 171.8 mm |
| Long description | Orbital motors are distinguished by their compact construction, large axial, radial shaft loads and high starting torque |
| Main port center to front flange distance | 127.5 mm |
| Main port thread diameter | 7/8 Inch |
| Main port threads per inch | 14 |
| Main port thread type | UNF |
| Main second port center to front flange distance | 149.5 mm |
| Max. continous working pressure | 210 BAR |
| Max continuous torque | 305 N·m |
| Max. flow rate | 75 l/min |
| Max intermittend working pressure | 275 BAR |
| Max. power | 18 kW |
| Max pressure peak | 295 BAR |
| Max rotation speed | 750 r/min |
| Min rotation speed | 10 r/min |
| Number of mounting holes | 4 |
| Original number equivalent | 151F2201 |
| Product details | Particularly suitable for continuous use in tough conditions, High continuous operating pressure, Very consistent operation at low speeds, Frequent reversing possible, High efficiency, Excellent start-up properties, Very high permissible radial load on the shaft is possible |
| Sealing type | Standard |
| Shaft diameter | 31.8 mm |
| Shaft type | Straight parallel |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 10300 g |
| Dimensions | 410 × 170 × 155 mm |
| Dangerous goods | No |
